WATERPROOF SPEAKERS
HY series (CE)
HY series (CE)
HY-313OB, HY-313OBT; HY-513OB, HY-513OBT; HY-620OB, HY-620OBT; HY-820OB, HY-820OBT (CE)
DETAIL
3-1/2" 2-WAY
WATERPROOF (IP 55)
. ANTI-UV CABINET
. Woofer Magnet: 8 Oz
. P.P. Mica Cone Rubber edge
. 13mm l Dome Tweeter
. Sensitivity: 86 dB (+/- 2dB)
. Freq. Response: 90Hz - 20K Hz
. Max. Recommended
Amplifier Power: 75W
. Impedance: 8 Ohms
. W/ Mounting Brackets
HY-313OBT
. With 100V Transformer
10W/5W/2.5W, 8 Ohms.
HY-513OB
5-1/4" 2-WAY
WATERPROOF (IP 55)
. ANTI-UV CABINET
. Woofer Magnet: 10 Oz
. P.P. Mica Cone Rubber edge
. 13mm l Dome Tweeter
. Sensitivity: 87 dB (+/- 2dB)
. Freq. Response: 67Hz - 20K Hz
. Max. Recommended
Amplifier Power: 110W
. Impedance: 8 Ohms
. W/ Mounting Brackets
HY-513OBT
. With 100V Transformer
30W/15W/7.5W, 8 Ohms.
HY-620OB
6-1/2" 2-WAY
WATERPROOF (IP 55)
. ANTI-UV CABINET
. Woofer Magnet: 20 Oz
. P.P. Mica Cone Rubber edge
. 20 mm Dome Tweeter
. Sensitivity: 88 dB (+/- 2dB)
. Freq. Response: 58Hz - 20K Hz
. Max. Recommended
Amplifier Power: 125W
. Impedance: 8 Ohms
. W/ Mounting Brackets
HY-620OBT
. With 100V Transformer
40W/20W/10W, 8 Ohms.
HY-820OB
8" 2-WAY
WATERPROOF (IP 55)
. ANTI-UV CABINET
. Woofer Magnet: 30 Oz
. P.P. Mica Cone Rubber edge
. 20 mm Dome Tweeter
. Sensitivity: 89 dB (+/- 2dB)
. Freq. Response: 52Hz - 20K Hz
. Max. Recommended
Amplifier Power: 150W
. Impedance: 8 Ohms
. W/ Mounting Brackets
HY-820OBT
. With 100V Transformer
50W/25W/12.5W, 8 Ohms.
